76.8V 100Ah Golf Cart Battery
Support OEM and ODM service, if you have any needs, you can contact us
Nominal Voltage
76.8V
Nominal Capacity
100 Ah
Energy
7680Wh
Recommended Charge Voltage
85.2 V – 87.6 V
Maximum Charge Current
100A
Maximum Continuous Discharge Current
100A
Peak Discharge Current
600A(3-5S)
BMS Discharge Voltage Cut-Off
60 V (2.5 ±0.05 v) (1-2s)
Dimensions (L x W x H)
780（810）x 320（350）x 220 mm
Weight
65KG
Storage Temperature
14 to 113 °F (-10 to 45°C)
Discharge Temperature
-4 to 140 °F (-20 to 60 °C)
Charge Temperature
32 to 131 °F (0 to 55 °C)
